一、logstash的使用

1.logstash配置文件

[root@m01 ~]# vim /etc/logstash/logstash.yml
path.config: /etc/logstash/conf.d

2.logstash收集日志文件到文件

1）配置logstash

[root@m01 conf.d]# vim message.conf
input {
  file {
    type => "message-log"
    path => "/var/log/messages"
    start_position => "beginning"
  }
}
output {
  file {
    path => "/tmp/message_%{+YYYY.MM.dd}.log"
  }
}

#启动
[root@m01 ~]# /usr/share/logstash/bin/logstash -f /etc/logstash/conf.d/message.conf &

3.logstash收集日志文件到ES

1）配置logstash

[root@m01 ~]# vim /etc/logstash/conf.d/test_es.conf
input {
  file {
    type => "message-log"
    path => "/var/log/messages"
    start_position => "beginning"
  }
}
output {
  elasticsearch {
    hosts => ["10.0.0.91:9200"]
    index => "test_es_%{+YYYY-MM-dd}"
  }
}

4.logstash启动多实例

#创建不同数据目录
[root@m01 ~]# mkdir /data/logstash/file_es -p
[root@m01 ~]# mkdir /data/logstash/file_file -p
[root@m01 ~]# chown -R logstash.logstash /data/logstash/

#启动的时候加 --path.data参数，指定启动后数据目录
[root@m01 ~]# /usr/share/logstash/bin/logstash -f /etc/logstash/conf.d/test_es.conf --path.data=/data/logstash/file_es &
[root@m01 ~]# /usr/share/logstash/bin/logstash -f /etc/logstash/conf.d/message.conf --path.data=/data/logstash/file_file &

5.收集多个文件日志到文件测试

1）配置logstash

[root@m01 conf.d]# vim system.conf
input {
  file {
    type => "message-log"
    path => "/var/log/messages"
    start_position => "beginning"
  }
  file {
    type => "secure-log"
    path => "/var/log/secure"
    start_position => "beginning"
  }
}
output {
  if [type] == "message-log" {
    file {
      path => "/tmp/message_%{+YYYY.MM.dd}.log"
    }
  }
  if [type] == "secure-log" {
    file {
      path => "/tmp/secure_%{+YYYY.MM.dd}.log"
    }
  }
}

2）启动

[root@m01 conf.d]# vim system.conf
input {
  file {
    type => "message-log"
    path => "/var/log/messages"
    start_position => "beginning"
  }
  file {
    type => "secure-log"
    path => "/var/log/secure"
    start_position => "beginning"
  }
}
output {
  elasticsearch {
    hosts => ["10.0.0.91:9200"]
    index => "%{type}_%{+YYYY-MM-dd}"
  }
}

二、使用logstash收集tomcat日志

1.安装tomcat

2.配置logstash收集tomcat日志

#一般企业里收集tomcat日志，如果有报错的话，会生成很多行数据，查看比较麻烦
修改方式：
1.修改tomcat日志为json格式
    1）开发自己更改，通过程序代码，或者log4j
    2）运维修改tomcat的server配置文件
2.通过Logstash其他模块来收集例：multiline多行匹配

1）配置

[root@m01 conf.d]# vim tomcat.conf
input {
  file {
    type => "tomcat-log"
    path => "/usr/local/tomcat/logs/localhost_access_log.*.txt"
    start_position => "beginning"
  }
}
output {
  elasticsearch {
    hosts => ["10.0.0.91:9200"]
    index => "tomcat_%{+YYYY.MM.dd}"
  }
}

3.方法一：修改tomcat日志格式为 json 格式

1）修改格式

[root@m01 ~]# vim /usr/local/tomcat/conf/server.xml
        <!--Valve className="org.apache.catalina.valves.AccessLogValve" directory="logs"
               prefix="localhost_access_log" suffix=".txt"
               pattern="%h %l %u %t &quot;%r&quot; %s %b" /-->
        <Valve className="org.apache.catalina.valves.AccessLogValve" directory="logs"
               prefix="tomcat_access" suffix=".log"
               pattern="{&quot;clientip&quot;:&quot;%h&quot;,&quot;ClientUser&quot;:&quot;%l&quot;,&quot;authenticated&quot;:&quot;%u&quot;,&quot;AccessTime&quot;:&quot;%t&quot;,&quot;method&quot;:&quot;%r&quot;,&quot;status&quot;:&quot;%s&quot;,&quot;SendBytes&quot;:&quot;%b&quot;,&quot;Query?string&quot;:&quot;%q&quot;,&quot;partner&quot;:&quot;%{Referer}i&quot;,&quot;AgentVersion&quot;:&quot;%{User-Agent}i&quot;}"/>

2）重启tomcat

[root@m01 ~]# /usr/local/tomcat/bin/shutdown.sh
Using CATALINA_BASE:   /usr/local/tomcat
Using CATALINA_HOME:   /usr/local/tomcat
Using CATALINA_TMPDIR: /usr/local/tomcat/temp
Using JRE_HOME:        /usr
Using CLASSPATH:       /usr/local/tomcat/bin/bootstrap.jar:/usr/local/tomcat/bin/tomcat-juli.jar
[root@m01 ~]# /usr/local/tomcat/bin/startup.sh
Using CATALINA_BASE:   /usr/local/tomcat
Using CATALINA_HOME:   /usr/local/tomcat
Using CATALINA_TMPDIR: /usr/local/tomcat/temp
Using JRE_HOME:        /usr
Using CLASSPATH:       /usr/local/tomcat/bin/bootstrap.jar:/usr/local/tomcat/bin/tomcat-juli.jar
Tomcat started.

3）查看新的日志

[root@m01 logs]# tail -f tomcat_access.2020-05-21.log
{"clientip":"10.0.0.1","ClientUser":"-","authenticated":"-","AccessTime":"[21/May/2020:11:46:09 +0800]","method":"GET /webdir/ HTTP/1.1","status":"304","SendBytes":"-","Query?string":"","partner":"-","AgentVersion":"Mozilla/5.0 (Windows NT 10.0; WOW64) AppleWebKit/537.36 (KHTML, like Gecko) Chrome/75.0.3770.100 Safari/537.36"}
{"clientip":"10.0.0.1","ClientUser":"-","authenticated":"-","AccessTime":"[21/May/2020:11:46:10 +0800]","method":"GET /favicon.ico HTTP/1.1","status":"200","SendBytes":"21630","Query?string":"","partner":"http://10.0.0.61:8080/webdir/","AgentVersion":"Mozilla/5.0 (Windows NT 10.0; WOW64) AppleWebKit/537.36 (KHTML, like Gecko) Chrome/75.0.3770.100 Safari/537.36"}

4）收集新的tomcat日志

[root@m01 ~]# vim /etc/logstash/conf.d/tomcat.conf
input {
  file {
    type => "tomcat-log"
    path => "/usr/local/tomcat/logs/tomcat_access.*.log"
    start_position => "beginning"
  }
}
output {
  elasticsearch {
    hosts => ["10.0.0.91:9200"]
    index => "tomcat_json_%{+YYYY.MM.dd}"
  }
}

4.方法二：通过Logstash其他模块来收集例：multiline多行匹配

1）测试匹配多行

[root@m01 ~]# vim /etc/logstash/conf.d/java.conf
input {
  stdin {
      #调用匹配合并模块
    codec => multiline {
         #遇到以 [ 开头的开始合并
      pattern => "^\["
      #匹配到上面指定的 字符 进行合并   如果是false 则没匹配到进行合并
      negate => true
      #向上合并   如果是next是向下合并
      what => "previous"
    }
  }
}
output {
  stdout {
    codec => json
  }
}

2）启动

[root@m01 ~]# /usr/share/logstash/bin/logstash -f /etc/logstash/conf.d/java.conf

3）测试

#输入一堆内容，没有打印出来，需要输入一个以[开头的数据，才会打印出来数据

123
qwe
asd
zxc
[
{"message":"123\nqwe\nasd\nzxc","@version":"1","tags":["multiline"],"host":"m01","@timestamp":"2020-05-21T04:06:03.483Z"}

5.将收集的日志写入ES

1）配置

[root@m01 ~]# vim /etc/logstash/conf.d/java.conf
input {
  file {
    path => "/usr/local/tomcat/logs/tomcat_access.*.log"
    type => "tomcat_access_log"
    start_position => "end"
    codec => multiline {
      pattern => "^\["
      negate => true
      what => "previous"
    }
  }
}
output {
  elasticsearch {
    hosts => ["10.0.0.91:9200"]
    index => "tomcat_access_log_%{+YYYY.MM.dd}"
    codec => "json"
  }
}

2）启动、测试

三、使用logstash收集nginx日志

1.安装nginx

#配置nginx
http {
    ... ...
    log_format  json  '{"@timestamp":"$time_iso8601",'
                      '"host":"$server_addr",'
                      '"clientip":"$remote_addr",'
                      '"size":$body_bytes_sent,'
                      '"responsetime":$request_time,'
                      '"upstreamtime":"$upstream_response_time",'
                      '"upstreamhost":"$upstream_addr",'
                      '"http_host":"$host",'
                      '"url":"$uri",'
                      '"referer":"$http_referer",'
                      '"agent":"$http_user_agent",'
                      '"status":"$status"}';

    access_log  /var/log/nginx/access_json.log  json;
    #access_log  /var/log/nginx/access.log  main;
    ... ...
}

2.配置收集nginx日志到ES

[root@m01 conf.d]# vim nginx.conf
input {
  file {
    path => "/var/log/nginx/access_json.log"
    type => "nginx_access_log"
    start_position => "end"
  }
}
output {
  elasticsearch {
    hosts => ["10.0.0.91:9200"]
    index => "nginx_access_log_%{+YYYY.MM.dd}"
  }
}
